The XSSR-W10 is a compact and reliable three-phase AC solid state relay designed for industrial power control and automation applications. Featuring opto-electronic isolation, built-in RC snubber protection, and LED status indication, it provides stable switching performance for three-phase AC loads. Available with either DC or AC control input options, the XSSR-W10 supports load currents from 10A to 120A and offers both zero-crossing and random turn-on versions to accommodate different load requirements. Its compact bolt-mount housing makes installation simple while ensuring long-term operational reliability.
Control Voltage: 3–32VDC / 80–250VAC
Load Voltage: 24–480VAC
Rated Load Current: 10A–120A


Solid-state construction eliminates mechanical contacts, ensuring long service life and silent operation.

Space-saving housing design enables convenient installation while maintaining excellent mechanical strength.

Built-in LED indicator provides clear visual confirmation of relay operation.

Integrated surge suppression circuit helps protect the relay from voltage transients and improves reliability.

Available in zero-crossing and random-fire versions to match different application requirements.

Uses bidirectional thyristor or anti-parallel thyristor technology for reliable AC load switching performance.

Provides electrical isolation between control and load circuits, enhancing system safety and noise immunity.

Supports load currents from 10A to 120A, suitable for heaters, industrial machinery, motors, and automation equipment.

Available with DC input (3–32VDC) or AC input (80–250VAC) to support a wide variety of control circuits.

Designed for efficient switching and control of three-phase AC loads in industrial automation and power control systems.
| Product model | XSSR-3DA48□W10 | XSSR-3AA48□W10 |
| Control voltage | 3-32VDC | 80-250VAC |
| Control current | 10-30mA | 10-30mA |
| Reverse voltage | 32VDC | / |
| Guarantee close voltage | 1VDC | 30VAC |
| Guarantee open voltage | 3VDC | 80VAC |
| Load voltage | 24-480VAC | |
| Load max current | 10A-120A | |
| Load mini current | 0.08A | |
| Breakover voltage | ≤1.8VAC | |
| Output leakage current | ≤8mA | |
| Medium withstand voltage | ≥2500VAC | |
| Insulating resistance | ≥100MΩ | |
| Switching time | ≤10mS | |
| Frequency range | 50-60Hz | |
| Operating temperature | -20-70℃ | |
| load current safety factor | Resistive load 50-60% | |
| Inductive load 30-40% | ||
Compliant with GB national standards, with CCC and CQC certification for domestic sales and bidding compliance.
Comply with CE, RoHS, REACH and EN standards, approved by TÜV & VDE, and support ATEX certification for explosive hazardous areas.
UL, CUL and CSA certified, conforming to North American electrical safety specifications for US and Canada market access.
Adapt to Japanese PSE and Korean KC certification, follow JIS and KS local standards to meet market access regulations of Japan and South Korea.
