The XSSR-W5 series is a high-capacity single-phase AC solid state relay designed for industrial power switching and heavy-duty load control applications. Featuring opto-isolated input, built-in RC snubber circuit, MOV surge protection, and LED status indication, it delivers reliable switching performance and enhanced protection against electrical transients. Its screw-mount structure and wide current range make it suitable for heating systems, industrial automation, temperature control equipment, packaging machinery, and power distribution systems.
Load Voltage: 75–480VAC
Control Voltage: 3–32VDC
Rated Load Current: 10A–125A


Robust screw-terminal construction allows secure installation and reliable operation in industrial environments.

Ensures safe electrical isolation between control and load circuits while improving noise immunity.

Provides clear visual indication of relay operating status for convenient monitoring and troubleshooting.

Integrated MOV protection helps absorb transient overvoltages and protects internal components.

Reduces voltage spikes and switching noise, improving reliability when controlling inductive loads.

Supports load currents up to 125A for demanding industrial and power control applications.
| Product model | XSSR-DA48□W5 |
| Control voltage | 3-32VDC |
| Control current | 6-25mA |
| Reverse voltage | 32VDC |
| Guarantee close voltage | 1VDC |
| Guarantee open voltage | 3VDC |
| Load voltage | 75-480VAC |
| Load max current | 10A-125A |
| Load mini current | 0.08A |
| Breakover voltage | ≤1.8VAC |
| Output leakage current | ≤8mA |
| Medium withstand voltage | ≥2500VAC |
| Insulating resistance | ≥100MΩ |
| Switching time | ≤10mS |
| Frequency range | 50-60Hz |
| Operating temperature | -20-70℃ |
| Load current safety factor | Resistive load 50-60% |
| Inductive load 30-40% |
Compliant with GB national standards, with CCC and CQC certification for domestic sales and bidding compliance.
Comply with CE, RoHS, REACH and EN standards, approved by TÜV & VDE, and support ATEX certification for explosive hazardous areas.
UL, CUL and CSA certified, conforming to North American electrical safety specifications for US and Canada market access.
Adapt to Japanese PSE and Korean KC certification, follow JIS and KS local standards to meet market access regulations of Japan and South Korea.
